Description
The Druck PV212-23 is a high-quality hydraulic hand pump designed for fast and reliable generation of pressures up to 1000 bar (15,000 psi). It is ideal for field and workshop calibration of pressure gauges, transmitters, switches, sensors and other pressure instruments.
The dual-stage pumping system features a selector valve for quick priming and efficient high-pressure generation with reduced operator effort. A built-in fine-adjust vernier provides precise pressure control, even at high pressures, while the 100 cc transparent reservoir allows easy monitoring of the hydraulic fluid level and can be refilled during operation.
Designed for use with mineral oil or distilled water, the PV212-23 provides a versatile and portable pressure source for calibration, testing and maintenance applications. Its rugged construction and straightforward operation make it suitable for demanding industrial and field environments.
| Attribute | Specification |
|---|---|
| Brand | Druck |
| Series | PV212 |
| Model | PV212-23 |
| Product Type | Hydraulic Hand Pump |
| Operation | Manual / Hand Operated |
| Pressure Type | Hydraulic |
| Pressure Range | 0 to 1000 bar |
| Pressure Range (psi) | 0 to 15,000 psi |
| Maximum Pressure | 1000 bar (15,000 psi) |
| Pump Type | Dual-Stage Hydraulic Pump |
| Pressure Generation | Manual scissor-action pumping |
| Priming System | High-pressure / priming selector valve |
| Fine Adjustment | Built-in vernier adjustment |
| Reservoir Capacity | 100 cc |
| Reservoir Type | Transparent |
| Reservoir Filling | Can be filled during operation |
| Compatible Fluid Media | Mineral oil or distilled water |
| Pressure Connections | 1/4 in BSP female |
| Pressure Ports | Reference instrument and test instrument connections |
| Pressure Release | Controlled pressure release; optional relief valve available |
| Primary Application | Pressure generation and calibration |
| Suitable Instruments | Pressure gauges, transmitters, switches, sensors and indicators |
| Typical Use | Field calibration, workshop testing and instrument maintenance |
| Design | Portable hand-operated construction |
| Optional Overpressure Protection | PRV212 pressure relief valve |
| Compatible Hose Kits | HK212 Series |
| Manufacturer | Druck |
Standard Accessories (Included)
For the PV212-23 pump-only configuration, the standard supplied item is:
- Druck PV212-23 Hydraulic Hand Pump
Ordering Info
- Part Number: PV212-22-P ; 0 to 700 bar (0 to 10,000 psi)
- Part Number: PV212-23-P ; 0 to 1000 bar (0 to 15,000 psi)
The high-pressure hose kit, adaptor set, carrying case, pressure relief valve and test gauge should not be listed as standard included accessories unless your supplier’s specific package confirms them. Druck identifies hose kits and the PRV212 pressure relief valve as optional accessories, while complete hydraulic test kits may include additional components.
You can view the official Druck PV212 product page and PV212 datasheet for manufacturer documentation.
